8.1.5 FACTORY HIERARCHICAL TABLE
Large Item
Variable / Adjustment Range Remarks
Middle Item
Small Item
8.2.1 INFORMATION
8.2.1.1 VERSION (1)
8.2.1.2 VERSION (2)
CLEAR <=> OFF <=> ON
8.2.1.3 MAIN NG
8.2.1.4 TEMPERATURE
8.2.1.5 HOUR METER
8.2.1.6 HDMI SIGNAL INFO 1
8.2.1.7 HDMI SIGNAL INFO 2
8.2.1.8 VDEC SIGNAL INFO
8.2.2 PANEL FACTORY (+)
8.2.2.1 PANEL INFORMATION
8.2.2.2 PANEL WORKS
8.2.2.3 POWER DOWN
8.2.2.4 SHUT DOWN
8.2.2.5 PANEL-1 ADJ (+) X-SUS B <=> 120 to 136 Equivalent to XSB
Y-SUS B <=> 120 to 136 Equivalent to YSB
Y-SUSTAIL T1 <=> 120 to 136 Equivalent to YTG
Y-SUSTAIL T2 <=> 120 to 136 Equivalent to YTB
Y-SUSTAIL W <=> 120 to 136 Equivalent to YTW
XY-RST W1 <=> 120 to 136 Equivalent to RSW
XY-RST W2 <=> 120 to 136 Equivalent to RYW
VOL SUS <=> 000 to 255 Equivalent to VSU
VOL OFFSET <=> 000 to 255 Equivalent to VOF
VOL RST P <=> 000 to 255 Equivalent to VRP
SUS FREQ. <=> MODE 1 to MODE 8 Equivalent to SFR
8.2.2.6 PANEL-2 ADJ (+) R-HIGH <=> 000 to 511 Equivalent to PRH
G-HIGH <=> 000 to 511 Equivalent to PGH
B-HIGH <=> 000 to 511 Equivalent to PBH
R-LOW <=> 000 to 999 Equivalent to PRL
G-LOW <=> 000 to 999 Equivalent to PGL
B-LOW <=> 000 to 999 Equivalent to PBL
ABL <=> 000 to 255 Equivalent to ABL
8.2.2.7 PANEL REVISE (+) R-LEVEL <=> LV-0 to LV-7 Equivalent to RRL
G-LEVEL <=> LV-0 to LV-7 Equivalent to RGL
B-LEVEL <=> LV-0 to LV-7 Equivalent to RBL
8.2.2.8 ETC. (+) BACKUP DATA <=> NO OPRT <=> TRANSFER or ERR Equivalent to BCP
DIGITAL EEPROM <=> NO OPRT <=> DELETE/REPAIR Equivalent to FAJ/UAJ
PD INFO. <=> NO OPRT <=> CLEAR Equivalent to CPD
SD INFO. <=> NO OPRT <=> CLEAR Equivalent to CSD
HR-MTR INFO. <=> NO OPRT <=> CLEAR Equivalent to CHM
PM/B1-B5 <=> NO OPRT <=> CLEAR Equivalent to CPM
P COUNT INFO. <=> NO OPRT <=> CLEAR
R MASK LEVEL <=> 000 to 255
G MASK LEVEL <=> 000 to 255
B MASK LEVEL <=> 000 to 255
Equivalent to CPC
MAX TEMP. <=> NO OPRT <=> CLEAR Equivalent to CMT
8.2.2.9 RASTER MASK SETUP (+) MASK OFF Equivalent to MKS+S00
RST MASK 01 <=> <=> 48V <=> 50V <=> 60V <=>
60P <=> 70P <=> 72V <=> 75V <=>
<=> 48V <=> 50V <=> 60V <=>
60P <=> 70P <=> 72V <=> 75V <=>
<=> 48V <=> 50V <=> 60V <=>
60P <=> 70P <=> 72V <=> 75V <=>
Equivalent to MKS+S51
• • • • • •
RST MASK 24 <=> Equivalent to MKS+S74
8.2.2.10 PATTEN MASK SETUP (+) MASK OFF Equivalent to MKS+S00
PTN MASK 01 <=> Equivalent to MKS+S01
• • • • • •
PTN MASK 39 <=> Equivalent to MKS+S39
8.2.2.11 COMBI MASK SETUP (+) MASK OFF Equivalent to MKC+S00
CMB MASK 01 <=> Equivalent to MKC+S01
• • • • • •
CMB MASK 10 <=> Equivalent to MKC+S10
Exclusively used for
production line
8.2.4 INITIALIZE
8.2.4.1 SYNC DET (+) for the technical analysis
8.2.4.2 SG MODE <=>
8.2.3 OPTION
8.2.3.1 EDID WRITE MODE <=>
8.2.3.2 CH PRESET <=>
SG OFF <=> • • •
SG PATTERN <=> COLOR BAR 1 • • •8.2.4.3 SG PATTERN <=>
8.2.4.4 SIDE MASK LEVEL (+)
INTR-POS1 (0x75) <=> 000 to 255
INTR-POS2 (0x76) <=> 000 to 255
INTR-POS3 (0x77) <=> 000 to 255
INTR-POS4 (0x78) <=> 000 to 255
8.2.4.7 HDMI INTR POSITION (+)
8.2.4.5 FINAL SETUP (+) DATA RESET <=> OFF <=> ON
8.2.4.6 CVT AUTO <=>
Exclusively used for
technical analysis
(details omitted)
