5.1.6 FLOWCHART OF FAILURE ANALYSIS FOR THE VIDEO SYSTEM
Flowchart of Failure Analysis for The Video System
Is the Terrestrial analog signal
not displayed?
Are the data displayed on the
"HDMI SIGNAL INFO" page of
the Factory menu correct?
The source equipment previously
used is in failure.
No problem with the MAIN Assy.
Is the sync signal output from
IC5401?
Does the result of SIG mode
detection on the Factory menu
coincide with the input signal data?
Yes
No
No
No
OK
After changing the source
equipment, check the "HDMI
SIGNAL INFO" data again.
NG
Replace the MAIN Assy.
No
Replace the MAIN Assy.
The input signal is not displayed.
⇒ ATV
Is the composite signal input not
displayed?
Yes
No
⇒ COMP / S1
Is the RGB signal input not
displayed?
Yes
⇒ RGB
Is the S-video signal input not
displayed?
Yes
No
Is the HDMI signal input not
displayed?
Yes
No
Is the component signal input not
displayed?
Yes
⇒ COMP / PC1
No
Is the PC signal input not
displayed?
Yes
⇒ COMP / PC2
No
Is the Terrestrial digital signal
not displayed?
Yes
⇒ DTV
No
Yes
Yes
Yes
Is the sync signal input to IC8001?
No
Replace the MAIN Assy.
Replace the MAIN Assy.
Yes
Replace the MAIN Assy.
Yes
No problem with the MAIN Assy.
⇒ COMP / S1
⇒ MA3

Pioneer PDP-507XA Specifications

General

3D	-
Depth	115 mm
Width	1224 mm
Height	717 mm
Weight	34100 g
Tuner type	Analog
Pixel pitch	- mm
Smart modes	Energy saving
Aspect ratio	16:9
Product color	Black
LED indicators	Y, Power
Noise reduction	Yes
RMS rated power	26 W
AC input voltage	220 - 240 V
Display diagonal	50 \
Channels quantity	99 channels
AC input frequency	50 - 60 Hz
Display brightness	1100 cd/m²
Display resolution	1365 x 768 pixels
Display technology	Plasma
Number of speakers	2
Teletext standards	Top-text
SCART ports quantity	3
Supported video modes	1080p
USB 2.0 ports quantity	0
Contrast ratio (typical)	4000:1
Annual energy consumption	- kWh
Display diagonal (metric)	127 cm
Analog signal format system	NTSC, NTSC 3.58, NTSC 4.43, PAL, PAL 60, PAL BG, PAL DK, PAL I, SECAM, SECAM B/G, SECAM D/K, SECAM L
Power consumption (standby)	0.3 W
Power consumption (typical)	341 W
Sound enhancement technology	FOCUS, SRS, TruBass
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 768 (WXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Component video (YPbPr/YCbCr) in	1
On Screen Display (OSD) languages	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, ITA, NOR, POL, POR, RUS, SWE, TUR
