Pioneer PDP-507XA User Manual

PDP-507XD
26
1234
1234
C
D
F
A
B
E
3. PCB PARTS LIST
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex.1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J=5%,
and K=10%).
Ex.2 When there are 3 effective digits (such as in high precision metal film resistors).
561
473
R50
1R0
5621
NOTES:
560 Ω
47k Ω
0.5 Ω
1 Ω
RD1/4PU J
RD1/4PU J
RN2H K
RS1P K
56 x 10
1
47 x 10
3
R50
1R0
561
473
5.62k Ω RN1/4PC F562 x 10
1
5621
MarkNo. Description Part No.
LIST OF ASSEMBLIES
NSP 1..PANEL CHASSIS (507) ASSY AWU1148
NSP 2..50 ADDRESS ASSY AWV2303
NSP 3..50 ADDRESS L ASSY AWW1141
NSP 3..50 ADDRESS S ASSY AWW1142
NSP 2..50 SCAN ASSY AWV2304
NSP 3..50 SCAN A ASSY AWW1147
NSP 3..50 SCAN B ASSY AWW1148
NSP 1..50 X DRIVE ASSY AWV2305
2..50 X MAIN DRIVE ASSY AWW1143
2..50 X SUB DRIVE ASSY AWW1144
NSP 1..50 Y DRIVE ASSY AWV2306
2..50 Y MAIN DRIVE ASSY AWW1145
2..50 Y SUB DRIVE ASSY AWW1146
NSP 1..50 DIGITAL ASSY AWV2302
2..50 DIGITAL ASSY AWW1139
2..SENSOR ASSY AWW1140
1..R07 DT ASSY (E) (507XD only) AWE1311
1..MAIN ASSY (STEPUP) AWV2318
NSP 1..I/O ASSY (STEPUP) AWV2319
2..TANSHI ASSY AWW1161
2..SIDE ASSY AWW1162
2..PC ASSY AWW1163
NSP 1..50 AUDIO FUKUGO ASSY AWV2346
2..AUDIO ASSY AWW1131
2..SP TERMINAL ASSY AWW1132
2..SIDE KEY ASSY AWW1133
2..50 LED ASSY AWW1135
2..LED IR ASSY AWW1136
> 1..POWER SUPPLY UNIT AXY1153
Mark No. Description Part No.
R07 DT ASSY (E) (507XD only)
MISCELLANEOUS
9 XNG1002
11 ANG2673
12–15 PMZ20P100FNI
16-18 ABZ30P060FTC
[TUNER BLOCK]
SEMICONDUCTORS
IC 1000 UPC3221GV
IC 1001 STV0361L
Q 1001 2SC2412K
Q 1002 DTC124EUA
Q 1003,1004 RK7002
>
D 1000 SM15T6V8A
D 1001 1SS355
MISCELLANEOUS
L 1000 XTX1005
L 1002 LCYAR82J2520
L 1004 XTX1003
L 1200 XTX1001
F 1000 XTF1002
F 1001,1003–1010 VTF1091
F 1012–1014,1100,1101 VTF1091
F 1202–1204 VTF1091
X 1100 XSS1010
>
FU 1200 XEK1003
>
M 1000 XXF1008
CAPACITORS
C 1001–1003,1017,1022 CKSRYB104K16
C 1004,1055 CEHVKW101M6R3
C 1010 CEHVKW2R2M50
C 1013,1021,1040,1041 CKSRYB103K50
C 1015 CKSRYB102K50
C 1018,1027,1029,1050 CEHVKW470M16
C 1019 CEHVKW100M50
C 1020 CEHVKW100M16
C 1025,1026,1030–1035 CKSRYB104K16
C 1028,1038,1042,1046 CCG1205
C 1036 CKSRYB105K10
C 1037,1039,1049,1053 CKSRYB104K16
C 1043,1044 CCSRCJ3R0C50
C 1045 CKSRYB103K50
C 1051 CCG1205
C 1054 BCG1050
C 1056,1057 CEHVKW470M16
C 1058–1062 CKSRYB104K16
C 1102 CEHVKW331M6R3
[DEMUX BLOCK]
SEMICONDUCTORS
IC 2000 STI5517DWAL
IC 2001 SN74LVU04APW
IC 2002 TC74VHC08FTS1
Q 2000 2SC4081
Mark No. Description Part No.

Pioneer PDP-507XA Specifications

General

3D	-
Depth	115 mm
Width	1224 mm
Height	717 mm
Weight	34100 g
Tuner type	Analog
Pixel pitch	- mm
Smart modes	Energy saving
Aspect ratio	16:9
Product color	Black
LED indicators	Y, Power
Noise reduction	Yes
RMS rated power	26 W
AC input voltage	220 - 240 V
Display diagonal	50 \
Channels quantity	99 channels
AC input frequency	50 - 60 Hz
Display brightness	1100 cd/m²
Display resolution	1365 x 768 pixels
Display technology	Plasma
Number of speakers	2
Teletext standards	Top-text
SCART ports quantity	3
Supported video modes	1080p
USB 2.0 ports quantity	0
Contrast ratio (typical)	4000:1
Annual energy consumption	- kWh
Display diagonal (metric)	127 cm
Analog signal format system	NTSC, NTSC 3.58, NTSC 4.43, PAL, PAL 60, PAL BG, PAL DK, PAL I, SECAM, SECAM B/G, SECAM D/K, SECAM L
Power consumption (standby)	0.3 W
Power consumption (typical)	341 W
Sound enhancement technology	FOCUS, SRS, TruBass
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 768 (WXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Component video (YPbPr/YCbCr) in	1
On Screen Display (OSD) languages	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, ITA, NOR, POL, POR, RUS, SWE, TUR
