(1) MULTIBASE SECTION PARTS LIST
(2) CONTRAST TABLE
PDP-507XD/WYVIXK5, PDP-507XA/WYVIXK5 and WYV5 are constructed the same except for the following:
Mark
No. Description Part No.
1 MAIN Assy AWV2308
2TANSHI Assy AWW1161
3 PC Assy AWW1163
4AUDIO Assy AWW1131
5 SP TERMINAL Assy AWW1132
6 R07 DT Assy See Contrast table (2)
7Ferrite Core ATX1044
8Ferrite Core ATX1063
9Ferrite Core ATX1064
10 Filter See Contrast table (2)
> 11 AC Inlet (CN1) AKP1301
12 Flexible Cable (J210) ADD1441
13 Flexible Cable (J211) ADD1441
14 Flexible Cable (J207) ADD1445
15 Flexible Cable (J214) See Contrast table (2)
16 Flexible Cable (J215) See Contrast table (2)
17 Flexible Cable (J213) See Contrast table (2)
18 13P&11P Housing Wire (J106) ADX3324
19 3P Housing Wire (J107) ADX3325
20 11P Housing Wire (J111) ADX3329
21 14P Housing Wire (J116) ADX3374
22 8/4P Housing Wire (J117) ADX3376
23 5P Housing Wire (J125) ADX3389
24 12P Housing Wire (J126) See Contrast table (2)
25 3P Housing Wire (J127) ADX3421
26 7/6/4/3P Housing Wire (J128) ADX3422
27 6P/3P Housing Wire (J129) ADX3423
28 Ferrite Stopper AEC1981
29 Binder AEC-093
30 Locking Card Spacer AEC1429
31 Wire Saddle AEC1745
32 Ferrite Core Holder AEC1818
33 Clamp AEC1884
34 Re-use Wire Saddle AEC1945
35 Locking Card Spacer AEC2019
36 Locking Card Spacer AEC2093
37 Inlet Spacer AEC2112
38 POD Cover See Contrast table (2)
39 Multi Base Assy See Contrast table (2)
40 Terminal Panel A See Contrast table (2)
> 41 Gasket N See Contrast table (2)
> 42 Gasket EA ANK1855
> 43 Gasket AD See Contrast table (2)
> 44 Gasket EB ANK1899
45 Filter CTX1054
46 • • • • •
47 Hex. Head Screw BBA1051
48 Screw AMZ30P060FTB
49 Screw See Contrast table (2)
50 Screw BMZ30P060FTB
51 Screw PMB30P080FNI
Mark
No. Description Part No.
Mark No. Symbol and Description
PDP-507XD
/WYVIXK5
PDP-507XA
/WYVIXK5
PDP-507XA
/WYV5
6 R07 DT Assy AWE1131 Not used Not used
10 Filter CTX1054 Not used Not used
15 Flexible Cable (J214) ADD1450 Not used Not used
16 Flexible Cable (J215) ADD1451 Not used Not used
17 Flexible Cable (J213) ADD1452 ADD1452 ADD1444
24 12P Housing Wire (J126) ADX3390 Not used Not used
38 POD Cover AMR3542 Not used Not used
39 Multi Base (E) Assy ANA1952 Not used Not used
39 Multi Base (G) Assy Not used ANA2019 ANA2019
40 Terminal Panel A (E/H) ANC2398 Not used Not used
40 Terminal Panel A (E/T) Not used ANC2399 ANC2399
> 41 Gasket N ANK1776 Not used Not used
> 43 Gasket AD ANK1863 Not used Not used
49 Screw BZ30P060FTB Not used Not used

Pioneer PDP-507XA Specifications

General

3D	-
Depth	115 mm
Width	1224 mm
Height	717 mm
Weight	34100 g
Tuner type	Analog
Pixel pitch	- mm
Smart modes	Energy saving
Aspect ratio	16:9
Product color	Black
LED indicators	Y, Power
Noise reduction	Yes
RMS rated power	26 W
AC input voltage	220 - 240 V
Display diagonal	50 \
Channels quantity	99 channels
AC input frequency	50 - 60 Hz
Display brightness	1100 cd/m²
Display resolution	1365 x 768 pixels
Display technology	Plasma
Number of speakers	2
Teletext standards	Top-text
SCART ports quantity	3
Supported video modes	1080p
USB 2.0 ports quantity	0
Contrast ratio (typical)	4000:1
Annual energy consumption	- kWh
Display diagonal (metric)	127 cm
Analog signal format system	NTSC, NTSC 3.58, NTSC 4.43, PAL, PAL 60, PAL BG, PAL DK, PAL I, SECAM, SECAM B/G, SECAM D/K, SECAM L
Power consumption (standby)	0.3 W
Power consumption (typical)	341 W
Sound enhancement technology	FOCUS, SRS, TruBass
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 768 (WXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Component video (YPbPr/YCbCr) in	1
On Screen Display (OSD) languages	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, ITA, NOR, POL, POR, RUS, SWE, TUR
