Pioneer PDP-507XA User Manual

PDP-507XD
76
1234
1234
C
D
F
A
B
E
SIDE KEY ASSY CN9501 (SW1) ↔ MAIN ASSY CN4010 (M8)
Pin No. Pin Name I/O Function Remarks
1 GND – GND –
2 KEY_AD2 O KEY voltage 2 –
3 KEY_AD1 O KEY voltage 1 –
4 V+3.3V_STB – Standby 3.3 V power supply –
LED IR ASSY CN9701 (RE1) ↔ MAIN ASSY CN4010 (M8)
Pin No. Pin Name I/O Function Remarks
1 V+5.1V_STB – Standby 5.1 V power supply –
2 REM O Remote control signal –
3 LED– – LED signal return –
4 LED_REC I LED control for REC H : LED_ON, L : LED_OFF
5 LED_MDM I – –
6 GND – GND –
50 LED ASSY CN9651 (L1) ↔ MAIN ASSY CN4006 (M5)
Pin No. Pin Name I/O Function Remarks
1 LED– – LED signal return –
2 LED_ON I LED control for power ON H : LED_ON, L : LED_OFF
3 LED_OFF I LED control for standby H : LED_ON, L : LED_OFF

Pioneer PDP-507XA Specifications

General

3D	-
Depth	115 mm
Width	1224 mm
Height	717 mm
Weight	34100 g
Tuner type	Analog
Pixel pitch	- mm
Smart modes	Energy saving
Aspect ratio	16:9
Product color	Black
LED indicators	Y, Power
Noise reduction	Yes
RMS rated power	26 W
AC input voltage	220 - 240 V
Display diagonal	50 \
Channels quantity	99 channels
AC input frequency	50 - 60 Hz
Display brightness	1100 cd/m²
Display resolution	1365 x 768 pixels
Display technology	Plasma
Number of speakers	2
Teletext standards	Top-text
SCART ports quantity	3
Supported video modes	1080p
USB 2.0 ports quantity	0
Contrast ratio (typical)	4000:1
Annual energy consumption	- kWh
Display diagonal (metric)	127 cm
Analog signal format system	NTSC, NTSC 3.58, NTSC 4.43, PAL, PAL 60, PAL BG, PAL DK, PAL I, SECAM, SECAM B/G, SECAM D/K, SECAM L
Power consumption (standby)	0.3 W
Power consumption (typical)	341 W
Sound enhancement technology	FOCUS, SRS, TruBass
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 768 (WXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Component video (YPbPr/YCbCr) in	1
On Screen Display (OSD) languages	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, ITA, NOR, POL, POR, RUS, SWE, TUR
