PDP-507XD

5678

CN3505 (D19) ↔ 50 X MAIN DRIVE ASSY CN1001 (X1)

Pin No. Pin Name I/O Function Voltage (V) TP

1 PSW2 O Function standby control signal 0 to 3.3 –

2 XSUS_PD I X drive PD signal 0 to 3.3 –

3 XDD_PD I X drive PD signal 0 to 3.3 –

4 XDRV_PD I X drive PD signal 0 to 3.3 –

5 GND – GND – –

6 SUS_MUTE O X drive control signal 0 to 3.3 –

7 XSUS_MSK O X drive control signal 0 to 3.3 –

8 GND – GND – –

9 XNR_D O X drive control signal 0 to 3.3 –

10 GND – GND – –

11 XSUS_G O X drive control signal 0 to 3.3 –

12 GND – GND – –

13 XSUS_D O X drive control signal 0 to 3.3 –

14 GND – GND – –

15 XSUS_U O X drive control signal 0 to 3.3 –

16 GND – GND – –

17 XSUS_B O X drive control signal 0 to 3.3 –

18 XCN_PD O X drive PD signal 0 to 3.3 –

AUDIO ASSY CN3752 (A2) ↔ MAIN ASSY CN4007 (M9)

Pin Function

AUDIO ASSY CN3753 (A3) ↔ SP TERMINAL ASSY CN3901 (SP1)

AUDIO ASSY CN3751 (A1) ↔ POWER SUPPLY UNIT (P5)

Pin No. Pin Name I/O Function Remarks

1 A_NG_B O DC detection, disconnection of cable detection L : Abnormal, H : Normal

2 GND – GND for small signal –

3 AUDIO_L I Small signal L ch –

4 GND – GND for small signal –

5 AUDIO_R I Small signal R ch –

6 GND – GND for small signal –

7 A_STBY_B I MUTE ON/OFF signal for LA4625 IC internal circuit L : Standby, H : ON

8 A_MUTE I MUTE ON/OFF signal for LA4625 IC external circuit L : MUTE OFF, H : MUTE

9 SCL_AU I CLK of I2C for NJW1183GK1 IC –

10 SDA_AU I/O DATA of I2C for NJW1183GK1 IC –

11 PSW_A I ON/OFF switch for 12 V regulator IC L : OFF, H : ON

Pin No. Pin Name I/O Function Remarks

1 +16.5V – Power supply (16.5 V) for LA4625 IC –

2 GND_D – Return GND for LA4625 IC –

3 GND_D – Return GND for LA4625 IC –

Pin No. Pin Name I/O Function Remarks

1 RH+ O Tweeter output R+ –

2 RL+ O Woofer output R+ (Speaker output R+) –

3 RH– O Tweeter output R– –

4 RL– O Woofer output R– (Speaker output R–) –

5 LL+ O Woofer output L+ (Speaker output L+) –

6 LH+ O Tweeter output L+ –

7 LL– O Woofer output L– (Speaker output L–) –

8 LH– O Tweeter output L– –
