Pioneer PDP-507XA User Manual

PDP-507XD
28
1234
1234
C
D
F
A
B
E
Q 6001,6009,6011,6200 DTC124EUA
Q 6003,6005,6010 DTA143EUA
Q 6006 2SB1188
Q 6008 TPC8209
Q 6100 2SC4081
D 6001 RSX201L-30
D 6003,6100–6102 1SS355
D 6103 UDZS30(B)
MISCELLANEOUS
L 6000 LCYAR82J2520
L 6001,6100,6101 XTH1001
F 6000 VTF1091
CN 6000 AKM1298
CN 6003 AKM1349
RESISTORS
R 6012–6014 RAB4C2R2J
R 6031 RAB4C221J
R 6204,6205 RAB4CQ101J
Other Resistors RS1/16S###J
CAPACITORS
C 6000,6026,6104–6106 CEHVKW331M6R3
C 6001,6011,6013–6015 CEHVKW470M16
C 6002,6035 CKSRYF223Z50
C 6003,6005,6006,6012 CKSRYF104Z16
C 6004 CEHVKW100M50
C 6008,6016 CKSRYF474Z16
C 6010 CCSRCH331J50
C 6017,6028,6036,6042 CEHVKW101M6R3
C 6018,6020,6021,6025 CKSRYF104Z16
C 6019,6023,6100 CEHVKW470M16
C 6022 CKSRYB103K50
C 6027 CCSRCH101J50
C 6029,6030,6033,6038 CKSRYF104Z16
C 6031 CEHVKW2R2M50
C 6044 CEHVKW101M6R3
C 6102 CCG1191
C 6200,6300 CKSRYF104Z16
50 DIGITAL ASSY
[DIGITAL IF BLOCK]
MISCELLANEOUS
F 3001 CCG1162
CN 3001 AKM1353
CN 3002 AKM1235
RESISTORS
R 3007,3010-3016 RAB4C470J
R 3020–3022 RAB4C103J
Other Resistors RS1/16SS###J
[MODULE UCOM BLOCK]
SEMICONDUCTORS
IC 3152,3153 SN74AHC541PW
IC 3155 SN74AHC08PW
IC 3156 BR24L04FJ-W
IC 3157 M62334FP
IC 3159 TC7W126FU
IC 3160,3161 TC74VHC123AFTS1
Q 3151 2SJ461A
Mark No. Description Part No.
D 3151,3152,3154,3155 DAN202U
D 3158,3159,3161–3163 1SS355
MISCELLANEOUS
X 3151 CSS1616
CN 3151 AKM1276
CN 3152 CKS4828
RESISTORS
R 3155,3160,3170,3176 RAB4C101J
R 3174 RAB4C103J
Other Resistors RS1/16SS###J
CAPACITORS
C 3151 CEHVKW470M6R3
C 3152,3153,3155–3158 CKSSYB104K10
C 3159,3171,3172,3182 CKSRYB105K6R3
C 3162,3163,3165,3166 CKSSYB104K10
C 3164 CCSSCH101J50
C 3167 CKSSYB103K16
C 3168,3170,3181 CKSSYB104K10
[PANEL FLASH BLOCK]
SEMICONDUCTORS
IC 3302,3305 PST3628UR
IC 3303 SN74AHC08PW
IC 3304 PST3610UR
Q 3301 RN1901
Q 3302 HN1C01FU
MISCELLANEOUS
X 3302 ASS1188
CN 3301 CKS4835
RESISTORS
R 3307,3308 RAB4C101J
Other Resistors RS1/16SS###J
CAPACITORS
C 3301–3303,3306,3308 CKSSYB104K10
C 3304,3307,3309 CKSSYB472K16
C 3305,3310 CKSSYB102K50
C 3311 CCSRCH470J50
C 3315,3316 CKSSYB104K10
C 3317 CCSRCH471J50
[SQ ASIC BLOCK]
SEMICONDUCTORS
IC 3401 PEG239A
MISCELLANEOUS
L 3401-3403 QTL1013
F 3401,3402 CCG1162
RESISTORS
R 3402,3412 RAB4C101J
R 3405–3407,3409,3410 RAB4C220J
R 3416 RAB4C220J
R 3425 RS1/16SS5601F
Other Resistors RS1/16SS###J
CAPACITORS
C 3401,3402,3419,3425 CEHVKW101M6R3
C 3403–3413,3417,3418 CKSSYB104K10
C 3420–3424,3426–3432 CKSSYB104K10
Mark No. Description Part No.

Pioneer PDP-507XA Specifications

General

3D	-
Depth	115 mm
Width	1224 mm
Height	717 mm
Weight	34100 g
Tuner type	Analog
Pixel pitch	- mm
Smart modes	Energy saving
Aspect ratio	16:9
Product color	Black
LED indicators	Y, Power
Noise reduction	Yes
RMS rated power	26 W
AC input voltage	220 - 240 V
Display diagonal	50 \
Channels quantity	99 channels
AC input frequency	50 - 60 Hz
Display brightness	1100 cd/m²
Display resolution	1365 x 768 pixels
Display technology	Plasma
Number of speakers	2
Teletext standards	Top-text
SCART ports quantity	3
Supported video modes	1080p
USB 2.0 ports quantity	0
Contrast ratio (typical)	4000:1
Annual energy consumption	- kWh
Display diagonal (metric)	127 cm
Analog signal format system	NTSC, NTSC 3.58, NTSC 4.43, PAL, PAL 60, PAL BG, PAL DK, PAL I, SECAM, SECAM B/G, SECAM D/K, SECAM L
Power consumption (standby)	0.3 W
Power consumption (typical)	341 W
Sound enhancement technology	FOCUS, SRS, TruBass
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 768 (WXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Component video (YPbPr/YCbCr) in	1
On Screen Display (OSD) languages	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, ITA, NOR, POL, POR, RUS, SWE, TUR
