PDP-507XD
64
1234
1234
C
D
F
A
B
E
50 DIGITAL Assy MAIN Assy
CN3001 (AKM1353)
Voltage
(V)
CN4001 (AKM1349)
No. Pin Name Pin Name No.
1 GND 0 GND 1
2 V_3.3V_UCOM 3.3 V_3.3V_UCOM 2
3 INP_MUTE 0 INP_MUTE 3
4 THEATER 0 THEATER 4
5VD 0/3.3 VD 5
6HD 0/3.3 HD 6
7DE 0/3.3 DE 7
8 GND 0 GND 8
9 CLK 0/3.3 CLK 9
10 GND 0 GND 10
11 GND 0 GND 11
12 VIDEO_R9 0 VIDEO_R9 12
13 VIDEO_R8 0 VIDEO_R8 13
14 VIDEO_R7 0 VIDEO_R7 14
15 VIDEO_R6 0 VIDEO_R6 15
16 VIDEO_R5 0 VIDEO_R5 16
17 VIDEO_R4 0 VIDEO_R4 17
18 VIDEO_R3 0 VIDEO_R3 18
19 VIDEO_R2 0 VIDEO_R2 19
20 VIDEO_R1 0 VIDEO_R1 20
21 VIDEO_R0 0 VIDEO_R0 21
22 GND 0 GND 22
23 VIDEO_G9 0 VIDEO_G9 23
24 VIDEO_G8 0 VIDEO_G8 24
25 VIDEO_G7 0 VIDEO_G7 25
26 VIDEO_G6 0 VIDEO_G6 26
27 VIDEO_G5 0 VIDEO_G5 27
28 VIDEO_G4 0 VIDEO_G4 28
29 VIDEO_G3 0 VIDEO_G3 29
30 VIDEO_G2 0 VIDEO_G2 30
31 VIDEO_G1 0 VIDEO_G1 31
32 VIDEO_G0 0 VIDEO_G0 32
33 GND 0 GND 33
34 VIDEO_B9 0 VIDEO_B9 34
35 VIDEO_B8 0 VIDEO_B8 35
36 VIDEO_B7 0 VIDEO_B7 36
37 VIDEO_B6 0 VIDEO_B6 37
38 VIDEO_B5 0 VIDEO_B5 38
39 VIDEO_B4 0 VIDEO_B4 39
40 VIDEO_B3 0 VIDEO_B3 40
41 VIDEO_B2 0 VIDEO_B2 41
42 VIDEO_B1 0 VIDEO_B1 42
43 VIDEO_B0 0 VIDEO_B0 43
44 GND 0 GND 44
45 Reserve 0 Reserve 45
46 AC_OFF 0 AC_OFF 46
47 TXD_MD 3.3 TXD_MD 47
48 RXD_MD 3.3 RXD_MD 48
49 REQ_MD 0 REQ_MD 49
50 MODE 0 MODE 50
TANSHI Assy MAIN Assy
CN8802 (AKM1349)
Voltage
(V)
CN4004 (AKM1349)
No. Pin Name Pin Name No.
1 Input3_G 2.4 Input3_G 50
2 GND 0 GND 49
3 Input3_B 2.4 Input3_B 48
4 GND 0 GND 47
5 Input3_R 2.4 Input3_R 46
6 GND 0 GND 45
7 Input1_G 2.4 Input1_G 44
8 GND 0 GND 43
9 Input1_B 2.4 Input1_B 42
10 GND 0 GND 41
11 Input1_R 2.4 Input1_R 40
12 GND 0 GND 39
13 RAPID_SW3 0 RAPID_SW3 38
14 RAPID_SW1 0 RAPID_SW1 37
15 GND 0 GND 36
16 LINK_IO3 4.9 LINK_IO3 35
17 GND 0 GND 34
18 LINK_IO2 4.9 LINK_IO2 33
19 SLOW_SW1 0 SLOW_SW1 32
20 SLOW_SW2 0 SLOW_SW2 31
21 SLOW_SW3 0 SLOW_SW3 30
22
IN2_CompY_PLUG
0
IN2_CompY_PLUG
29
23 GND 0 GND 28
24 Input2_Y 2.4 Input2_Y 27
25 GND 0 GND 26
26 Input2_Pb 2.4 Input2_Pb 25
27 GND 0 GND 24
28 Input2_Pr 2.4 Input2_Pr 23
29 GND 0 GND 22
30 Input3_V 0 Input3_V 21
31 GND 0 GND 20
32 Input3_SC 2.2 Input3_SC 19
33 GND 0 GND 18
34 Input2_V 0 Input2_V 17
35 GND 0 GND 16
36 Input2_SC 2.2 Input2_SC 15
37 GND 0 GND 14
38 Input1_V 2.6 Input1_V 13
39 GND 0 GND 12
40 AIR_OUT_V 3.4 AIR_OUT_V 11
41 GND 0 GND 10
42 SCART_OUT_V 3.6 SCART_OUT_V 9
43 GND 0 GND 8
44 Input1_Lch 4.5 Input1_Lch 7
45 GND 0 GND 6
46 Input1_Rch 4.5 Input1_Rch 5
47 GND 0 GND 4
48 Input2_Lch 4.5 Input2_Lch 3
49 GND 0 GND 2
50 Input2_Rch 4.5 Input2_Rch 1
