Pioneer PDP-507XA User Manual

PDP-507XD
68
1234
1234
C
D
F
A
B
E
CN3001 (D11) ↔ MAIN ASSY CN4001 (M1)
Pin No. Pin Name I/O Function Voltage (V) TP
1 GND – GND
2 V+3.3V_UCOM2 I Power supply for module microcomputer 3.3
–
0
–
–
–
–
–
–
–
–
3.3
3.3
0
0
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
3 INP_MUTE O Video signal input shut out control signal
4 THEATER I Control signal for pure cinema 0 to 3.3
5VDIVertical synchronized signal 0 to 3.3
6HDIHorizontal synchronized signal 0 to 3.3
0 to 3.3
8 GND – GND
7DEIData enable signal
9 CLK I Data clock signal
10 GND – GND
0 to 3.3
11 GND – GND
12 VIDEO_R9 I 10 bit video signal input (RED) 0 to 3.3
13 VIDEO_R8 I 10 bit video signal input (RED) 0 to 3.3
14 VIDEO_R7 I 10 bit video signal input (RED) 0 to 3.3
15 VIDEO_R6 I 10 bit video signal input (RED) 0 to 3.3
16 VIDEO_R5 I 10 bit video signal input (RED) 0 to 3.3
17 VIDEO_R4 I 10 bit video signal input (RED) 0 to 3.3
18 VIDEO_R3 I 10 bit video signal input (RED) 0 to 3.3
19 VIDEO_R2 I 10 bit video signal input (RED) 0 to 3.3
20 VIDEO_R1 I 10 bit video signal input (RED) 0 to 3.3
21 VIDEO_R0 I 10 bit video signal input (RED) 0 to 3.3
22 GND – GND
23 VIDEO_G9 I 10 bit video signal input (GREEN) 0 to 3.3
24 VIDEO_G8 I 10 bit video signal input (GREEN) 0 to 3.3
25 VIDEO_G7 I 10 bit video signal input (GREEN) 0 to 3.3
26 VIDEO_G6 I 10 bit video signal input (GREEN) 0 to 3.3
27 VIDEO_G5 I 10 bit video signal input (GREEN) 0 to 3.3
28 VIDEO_G4 I 10 bit video signal input (GREEN) 0 to 3.3
29 VIDEO_G3 I 10 bit video signal input (GREEN) 0 to 3.3
30 VIDEO_G2 I 10 bit video signal input (GREEN) 0 to 3.3
31 VIDEO_G1 I 10 bit video signal input (GREEN) 0 to 3.3
32 VIDEO_G0 I 10 bit video signal input (GREEN) 0 to 3.3
33 GND – GND
34 VIDEO_B9 I 10 bit video signal input (BLUE) 0 to 3.3
35 VIDEO_B8 I 10 bit video signal input (BLUE) 0 to 3.3
36 VIDEO_B7 I 10 bit video signal input (BLUE) 0 to 3.3
37 VIDEO_B6 I 10 bit video signal input (BLUE) 0 to 3.3
38 VIDEO_B5 I 10 bit video signal input (BLUE) 0 to 3.3
39 VIDEO_B4 I 10 bit video signal input (BLUE) 0 to 3.3
40 VIDEO_B3 I 10 bit video signal input (BLUE) 0 to 3.3
41 VIDEO_B2 I 10 bit video signal input (BLUE) 0 to 3.3
42 VIDEO_B1 I 10 bit video signal input (BLUE) 0 to 3.3
43 VIDEO_B0 I 10 bit video signal input (BLUE) 0 to 3.3
44 GND – GND
45 RESERVE (N.C.) – Reserve
46 AC_OFF (N.C.) O AC state input
47 TXD_MD O UART communication
48 RXD_MD I UART communication
49 REQ_MD O Communication demand to main system
50 MODE O Model distinction
50 DIGITAL ASSY

Pioneer PDP-507XA Specifications

General

3D	-
Depth	115 mm
Width	1224 mm
Height	717 mm
Weight	34100 g
Tuner type	Analog
Pixel pitch	- mm
Smart modes	Energy saving
Aspect ratio	16:9
Product color	Black
LED indicators	Y, Power
Noise reduction	Yes
RMS rated power	26 W
AC input voltage	220 - 240 V
Display diagonal	50 \
Channels quantity	99 channels
AC input frequency	50 - 60 Hz
Display brightness	1100 cd/m²
Display resolution	1365 x 768 pixels
Display technology	Plasma
Number of speakers	2
Teletext standards	Top-text
SCART ports quantity	3
Supported video modes	1080p
USB 2.0 ports quantity	0
Contrast ratio (typical)	4000:1
Annual energy consumption	- kWh
Display diagonal (metric)	127 cm
Analog signal format system	NTSC, NTSC 3.58, NTSC 4.43, PAL, PAL 60, PAL BG, PAL DK, PAL I, SECAM, SECAM B/G, SECAM D/K, SECAM L
Power consumption (standby)	0.3 W
Power consumption (typical)	341 W
Sound enhancement technology	FOCUS, SRS, TruBass
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 768 (WXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Component video (YPbPr/YCbCr) in	1
On Screen Display (OSD) languages	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, ITA, NOR, POL, POR, RUS, SWE, TUR
