Pioneer PDP-507XA User Manual

PDP-507XD
72
1234
1234
C
D
F
A
B
E
CN3503 (D17) ↔ 50 ADDRESS S ASSY CN1802 (AD1)
Pin No. Pin Name I/O Function Voltage (V) TP
1NC–Non connection
2
3
–
–
8
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
4 GND – GND
5 V+8V O +8 V power supply input
6 V+8V O +8 V power supply input 8
7 GND – GND –
8 GND_LVDS – GND
9NC–Non connection
10 TAN O LVDS data 1 to 1.4
11 TAP O LVDS data 1 to 1.4
12 NC – Non connection
13 GND_LVDS – GND
14 NC – Non connection
15 TBN O LVDS data 1 to 1.4
16 TBP O LVDS data 1 to 1.4
17 NC – Non connection
18 GND_LVDS – GND
19 NC – Non connection
20 TCN O LVDS data 1 to 1.4
21 TCP O LVDS data 1 to 1.4
22 NC – Non connection
23 GND_LVDS – GND
24 NC – Non connection
25 TCLKN O LVDS data 1 to 1.4
26 TCLKP O LVDS data 1 to 1.4
27 NC – Non connection
28 GND_LVDS – GND
29 NC – Non connection
30 TDN O LVDS data 1 to 1.4
31 TDP O LVDS data 1 to 1.4
32 NC – Non connection
33 GND_LVDS – GND
34 GND – GND
35 V+3.3V O +3.3 V power supply output 3.3
36 V+3.3V O +3.3 V power supply output 3.3
37 GND – GND
38 DIV1 O Data output timing control 3.3
39 DIV0 O Data output timing control 0
40 GND – GND
ADR_PD I Address PD signal
PSIZE I Panel size judge signal 0
0 to 3.3

Pioneer PDP-507XA Specifications

General

3D	-
Depth	115 mm
Width	1224 mm
Height	717 mm
Weight	34100 g
Tuner type	Analog
Pixel pitch	- mm
Smart modes	Energy saving
Aspect ratio	16:9
Product color	Black
LED indicators	Y, Power
Noise reduction	Yes
RMS rated power	26 W
AC input voltage	220 - 240 V
Display diagonal	50 \
Channels quantity	99 channels
AC input frequency	50 - 60 Hz
Display brightness	1100 cd/m²
Display resolution	1365 x 768 pixels
Display technology	Plasma
Number of speakers	2
Teletext standards	Top-text
SCART ports quantity	3
Supported video modes	1080p
USB 2.0 ports quantity	0
Contrast ratio (typical)	4000:1
Annual energy consumption	- kWh
Display diagonal (metric)	127 cm
Analog signal format system	NTSC, NTSC 3.58, NTSC 4.43, PAL, PAL 60, PAL BG, PAL DK, PAL I, SECAM, SECAM B/G, SECAM D/K, SECAM L
Power consumption (standby)	0.3 W
Power consumption (typical)	341 W
Sound enhancement technology	FOCUS, SRS, TruBass
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 768 (WXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Component video (YPbPr/YCbCr) in	1
On Screen Display (OSD) languages	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, ITA, NOR, POL, POR, RUS, SWE, TUR
