Pipistrel Sinus User Manual

K i t M a n u a l f o r P i p i s t r e l S i n u s a n d V i r u s A i r c r a f t
 Pull back the plastic on the bottom side of the screen to expose the line drawn earlier.
Even though the line is on the other side of the screen, it is still possible to see it ok.
 Hold the plastic back with masking tape and then using electricians plastic tape carefully
mark out the line for painting. It is important to sand the surface to be painted with 1000
grit sandpaper and remove all the shine
 Spray with the provided black bumper spray,one light coat first and then another after
about 2 minutes. If you leave it too long it will look a different colour to the first coat.
 Allow to dry for at least one day, if you don’t the paint will get scratched off when fitting
the screen, it must be allowed to harden, do not remove any of the tape until completely
dry.
 Now you can mount the windscreen and sunroof using the provided rivets. Be sure to
inspect all edges afterwards and make any necessary touch ups.
http://www.pipistrel.si © Pipistrel Release March 2009 © Page 122 of 267

Pipistrel Sinus Specifications

General

Manufacturer	Pipistrel
Seats	2
Rate of climb	5.5 m/s (1, 080 ft/min)
Ballistic parachute rescue system	Optional
Engine	Rotax 912
Type	Motor glider
