K i t M a n u a l f o r P i p i s t r e l S i n u s a n d V i r u s A i r c r a f t
 Continue preparing the windscreen and the sunroof by redrilling all the holes with a
4.5mm drillpiece. This is 0.5mm bigger than the rivets and will stop any cracks in the
lexan screens from developing due to engine vibration or temperature change.
 Using a countersinking tool, take the sharp edge off each hole at the top and bottom.
This will stop cracks from developing in the screen.
 Use a de-burring tool on the top and bottom of the screen and roof panel to give a nice
chamfered finish.
http://www.pipistrel.si © Pipistrel Release March 2009 © Page 121 of 267

Pipistrel Sinus Specifications

General

Manufacturer	Pipistrel
Seats	2
Rate of climb	5.5 m/s (1, 080 ft/min)
Ballistic parachute rescue system	Optional
Engine	Rotax 912
Type	Motor glider
