K i t M a n u a l f o r P i p i s t r e l S i n u s a n d V i r u s A i r c r a f t
 Run the black wire from the power supply connector to the strobe box.
 Then run both blue strobe wires from the strobe box, along the bottom of the bulkhead
and through the plastic loops already mounted for the fuel lines. The strobe wire should
follow the fuel lines from behind the cabin, through the hole with the rubber grommet, to
the wing root.
 Lastly, run the red/black wires from the connector to the microphone along the backside
of the central cabin beam.
http://www.pipistrel.si © Pipistrel Release March 2009 © Page 125 of 267

Pipistrel Sinus Specifications

General

Manufacturer	Pipistrel
Seats	2
Rate of climb	5.5 m/s (1, 080 ft/min)
Ballistic parachute rescue system	Optional
Engine	Rotax 912
Type	Motor glider
