K i t M a n u a l f o r P i p i s t r e l S i n u s a n d V i r u s A i r c r a f t
 Be sure to cover or place plugs in any openings that are created by removing elements.
 Remove the coolant canister and its rubber hoses. Rinse them clean.
 Mark the metal spouts at the end of of the houses with the same cylinder numbers you
marked the crankcase with before.
 Now remove the meal spouts and put plugs in the openings.
 Lastly, remove the main front bolt from the crankcase.
http://www.pipistrel.si © Pipistrel Release March 2009 © Page 128 of 267

Pipistrel Sinus Specifications

General

Manufacturer	Pipistrel
Seats	2
Rate of climb	5.5 m/s (1, 080 ft/min)
Ballistic parachute rescue system	Optional
Engine	Rotax 912
Type	Motor glider
