K i t M a n u a l f o r P i p i s t r e l S i n u s a n d V i r u s A i r c r a f t
 Now take the Pipistrel plastic ventilation cover and stick the pieces of foam provided in
the appropriate places. One piece should be placed on the inside of every leg and three
pieces need to be placed one on top of the other in the front. See pictures below.
 Fit the Pipistrel plastic ventilation cover back on the motor.
 Now fit the Pipisterl engine mount. The top bolt should be tightened with a torque
wrench to 27 N.m, while the two side bolts should be tightened to 35 N.m.
 Apply blue Loctite 243 to the threads first.
http://www.pipistrel.si © Pipistrel Release March 2009 © Page 129 of 267

Pipistrel Sinus Specifications

General

Manufacturer	Pipistrel
Seats	2
Rate of climb	5.5 m/s (1, 080 ft/min)
Ballistic parachute rescue system	Optional
Engine	Rotax 912
Type	Motor glider
