K i t M a n u a l f o r P i p i s t r e l S i n u s a n d V i r u s A i r c r a f t
 Now fit the the two coils with with the small 4mm-long bracket as shown in the photo
below.
 Then take the coils and fix them to the top ends of the A-shaped brackets, using blue
Loctite 243 as you go.
 Find the two 44mm-long brackets provided, which have a small groove in the edge at one end.
 Mount the first one at the bottom end of the A-bracket as shown in the photos below. Be sure to use a
polystop nut with blue Loctite 243.
http://www.pipistrel.si © Pipistrel Release March 2009 © Page 135 of 267

Pipistrel Sinus Specifications

General

Manufacturer	Pipistrel
Seats	2
Rate of climb	5.5 m/s (1, 080 ft/min)
Ballistic parachute rescue system	Optional
Engine	Rotax 912
Type	Motor glider
