Pipistrel Sinus User Manual

K i t M a n u a l f o r P i p i s t r e l S i n u s a n d V i r u s A i r c r a f t
 Find the gold-coloured fuel return pressure control jet. This needs to be fitted in the 4
th
spout. Tap the
spout and fit the jet. Be sure to place the jet, so that it's threads go into the spout last.
 Fit the 4
th
spout to the distributor with the two washer's provided and the special bolt, which has a small
hole in it's head.
 Now secure the upper spout using cablewire. Utilized the holes in the upper bolt's head and the
distributor. See photo's below.
http://www.pipistrel.si © Pipistrel Release March 2009 © Page 140 of 267

Pipistrel Sinus Specifications

General

Manufacturer	Pipistrel
Seats	2
Rate of climb	5.5 m/s (1, 080 ft/min)
Ballistic parachute rescue system	Optional
Engine	Rotax 912
Type	Motor glider
