Pipistrel Sinus User Manual

K i t M a n u a l f o r P i p i s t r e l S i n u s a n d V i r u s A i r c r a f t
 Lockwire all of the exhaust system joints which are fixed together by springs. See photos
below.
 Also lockwire the muffler to the L-shaped brace.
 Mount the exhaust temperature guards to the exhaust elbows which run from cylinder
heads 3 and 4. Use the hose clamps and toothed washers provided.
 Now mount the hose for the water pump as shown in the photo below. Mark the bolts
with red paint when finished.
http://www.pipistrel.si © Pipistrel Release March 2009 © Page 162 of 267

Pipistrel Sinus Specifications

General

Manufacturer	Pipistrel
Seats	2
Rate of climb	5.5 m/s (1, 080 ft/min)
Ballistic parachute rescue system	Optional
Engine	Rotax 912
Type	Motor glider
