K i t M a n u a l f o r P i p i s t r e l S i n u s a n d V i r u s A i r c r a f t
 Slide both the choke and throttle cable outers through the firewall as seen in the photo
below.
 Then feed the cable outers under the cabin floor through the hole under the avionics.
Proceed to feed back into the cabin through the appropriate holes under the
choke/throttle handle assembly. Fit the each outer to its corresponding handle.
 Do the same for the other end of the cables. Mount them into the appropriate fittings on
the carburetor cable control bracket.
http://www.pipistrel.si © Pipistrel Release March 2009 © Page 168 of 267

Pipistrel Sinus Specifications

General

Manufacturer	Pipistrel
Seats	2
Rate of climb	5.5 m/s (1, 080 ft/min)
Ballistic parachute rescue system	Optional
Engine	Rotax 912
Type	Motor glider
