K i t M a n u a l f o r P i p i s t r e l S i n u s a n d V i r u s A i r c r a f t
 Now prepare the actual cables. Fix (solder) one end of each cable with the bolt/pin fitting
shown in the photo below.
 Install one bolt/pin fitting into the choke handle and the other into the throttle handle.
Then fit the cable through the assembly and into the cable outer.
 Remove the handle covers to make this process easier.
