K i t M a n u a l f o r P i p i s t r e l S i n u s a n d V i r u s A i r c r a f t
 Make your way back to the carburetor cable control bracket, pull the cables tight to
ensure that they are taught and also check to see that the outers are sitting nicely in
their respective fittings.
 Line up the cable with the brace holder and mark the cable directly in the middle of the
hole. Trim the cable and solder a bolt/pin fitting to the end. Do the same for the other
cable.
 Once finished, cover the carburetor control joints with grease.
http://www.pipistrel.si © Pipistrel Release March 2009 © Page 170 of 267

Pipistrel Sinus Specifications

General

Manufacturer	Pipistrel
Seats	2
Rate of climb	5.5 m/s (1, 080 ft/min)
Ballistic parachute rescue system	Optional
Engine	Rotax 912
Type	Motor glider
