K i t M a n u a l f o r P i p i s t r e l S i n u s a n d V i r u s A i r c r a f t
 Finally, make a small cut for the brackets which hold the fuel lines in place and push
down firmly to complete the process
 Cut the holes for the wing spars, the fuel sight gauges and the other connectors using a
gas operated soldering iron with a sharpened point. You must use a soldering iron to both
cut and seal the carpet in one go. If the carpet is not sealed it will start to fray after its
first flight.
 Fit the fuel taps using Loctite number 243 which is made for fuel and pressure fittings.
Use a washer and position in the bracket as shown in the photograph.
http://www.pipistrel.si © Pipistrel Release March 2009 © Page 31 of 267

Pipistrel Sinus Specifications

General

Manufacturer	Pipistrel
Seats	2
Rate of climb	5.5 m/s (1, 080 ft/min)
Ballistic parachute rescue system	Optional
Engine	Rotax 912
Type	Motor glider
