K i t M a n u a l f o r P i p i s t r e l S i n u s a n d V i r u s A i r c r a f t
 Next drill two holes into the pushrod base area as shown in the picture below. One hole
should be just below the pushrod on the left hand side and the other just below the first
one, but on the right hand side. Your fuselage should already be marked with the proper
locations.
 The driver's left pedal rudder outer and the passenger's right pedal rudder outer should
cross here.
 The material is soft foam, so be careful when drilling. Use a vacuum to keep debris out of
the bearings.
