K i t M a n u a l f o r P i p i s t r e l S i n u s a n d V i r u s A i r c r a f t
 Clean the windscreen mounting areas with thinners or alcohol removers to ensure they
are clean and will bond properly. Blow them with compressed air and a vacuum to
ensure they are totally clean.
 Drill holes in the floor for the cables, flaps and the trim slot. Use the Dremel tool to cut
the holes and then sand smooth with a file and sandpaper. The same goes for the flap
handle area and also the throttle nutserts. The factory will already have these positions
marked for you in marker pen. Look at Appendix 2, 3 and 4 for hole diagrams with exact
dimensions.
http://www.pipistrel.si © Pipistrel Release March 2009 © Page 8 of 267

Pipistrel Sinus Specifications

General

Manufacturer	Pipistrel
Seats	2
Rate of climb	5.5 m/s (1, 080 ft/min)
Ballistic parachute rescue system	Optional
Engine	Rotax 912
Type	Motor glider
