BT37 MarkII: Service Manual MA200606 1.0.0
Component replacement
Fig.13 - Tearing off excess tinned copper tab
Fig.14 - showing the finished assembly
19. Gently check that the lid opens fully and that the ribbon cable does not interfere with
the hinge mechanism. This is important, because the ribbon cable cannot flex
properly at the hinge if it is too tight or too loose, and it will prevent the lid from
opening correctly; see fig.15. Re-position the cable as described at step 15 if
necessary.
