User Manual of VDR-301N
13
 Multiple SSIDs: It allows users to access different networks through a single AP.
 Management Features
 TR069 compliant: Support for centralized management node of multiple VDSL2 CPEs
1.4 Product Specifications
Model
VDR
-301N
Product Description
300Mbps
Wireless VDSL2 Bridge Router
Hardware Specifications
Interfaces
LAN
4 x 10/100BASE-TX, auto-negotiation, auto MDI/MDI-X RJ45
port
WAN 1 x RJ11, 1 x 1000BASE-T RJ45
Antenna
2.4GHz: 2 x 4dBi internal antennas
Button
1 x Power button
1 x Reset button
1 x WPS button
1 x WLAN button
LED Indicators PWR, DSL, LAN1-4, WLAN, WPS
Dimensions (W x D x
H)
155 x 60 x 152 mm
Weight
238g
Power 12V DC, 0.5A
Power Consumption 6W
Software Features
Internet Connection
Type

Bridge

PPPoE

Dynamic IP

Static IP
VDSL Features

ITU-T G.993.2 VDSL2

Supports 8a,8b,12a,12b,17a,30a profile

Supports G. vectoring

Supports ATM and PTM

Supports Annex A, B
