User Manual of VDR-301N
66
The following table describes the parameters:
Field Description
RIP
You can select Off or On.
Apply Click it to save the settings on this page.
Interface Choose the router interface that uses RIP.
Recv Version
Choose the interface version that receives RIP messages. You can
choose RIP1, RIP2, or Both.
 Choose RIP1 to indicate the router receives RIP v1 messages.
 Choose RIP2 to indicate the router receives RIP v2 messages.
 Choose Both to indicate the router receives RIP v1 and RIP v2
messages.
Send Version
The working mode for sending RIP messages. You can choose RIP1 or
RIP2.
 Choose RIP1 to indicate the router broadcasts RIP1 messages only.
 Choose RIP2 to indicate the router multicasts RIP2 messages only.
Add Click it to add the RIP interface to the Rip Config List.
Delete
Select a row in the Rip Config List and click it to delete the row.
5.4.2 NAT
Choose Advanced > NAT and the page shown in the following figure appears. The page displayed contains DMZ,
Virtual Server, ALG, NAT Exclude IP, Port Trigger, FTP ALG Port, and NAT IP Mapping.
5.4.2.1 DMZ
Demilitarized Zone (DMZ) is used to provide Internet services without sacrificing unauthorized access to its local
private network. Typically, the DMZ host contains devices accessible to Internet traffic, such as web (HTTP)
servers, FTP servers, SMTP (e-mail) servers and DNS servers.
Click DMZ in the left pane and the page shown in the following figure appears. The following describes how to
configure manual DMZ. Enter an IP address of the DMZ host. Click Apply Changes to save the settings on this
page temporarily.
