User Manual of VDR-301N
41
32 to 65535 (1 to 31 are reserved for known protocols)
Encapsulation
You can select LLC or VC-Mux.
Channel Mode
You can choose Bridge, IPoE, PPPoE, PPPoA, 1483 Routed, IPoA
Enable NAPT
Select it to enable Network Address Port Translation (NAPT) function. If
you do not select it and you want to access the Internet normally, you
must add a route on the uplink equipment. Otherwise, the access to the
Internet fails. Normally, it is enabled.
Enable IGMP
You can enable or disable Internet Group Management Protocol (IGMP)
function.
VLAN
You can select Disable or Enable the VLAN
VLAN ID You can enter the VLAN ID from 1 to 4095
IP Protocol
You can select IPv4, IPv4/IPv6 or IPv6.
PPP Settings
User Name
Enter the correct user name for PPP dial-up, which is provided by your
ISP.
Password
Enter the correct password for PPP dial-up, which is provided by your
ISP.
Type
You can choose Continuous, Connect on Demand, or Manual.
Idle Time (min)
To set the type to Connect on Demand, you need to enter the idle
timeout time. Within the preset minutes, if the router does not detect the
flow of the user continuously, the router automatically disconnects the
PPPoE connection.
WAN IP Settings
Type
You can choose Fixed IP or DHCP.
 To select Fixed IP, you should enter the local IP address, remote IP
address and subnet mask.
 To select DHCP, the router is a DHCP client and the WAN IP
address is assigned by the remote DHCP server.
Local IP Address Enter the IP address of WAN interface provided by your ISP.
Remote IP Address Enter the default gateway of WAN interface provided by your ISP.
Netmask Enter the subnet mask of the local IP address.
Default Route
Select Disable, Enable or Auto. The default setting is Auto.
Unnumbered Select this checkbox to enable IP unnumbered function.
Add
After configuring the parameters of this page, click it to add new WAN
