User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC
-18-
LAN
Static IP / DHCP Client
Supports IP-MAC binding
WAN Type (GW/WISP mode)
 Static IP
 Dynamic IP
 PPPoE
Wireless Modes
 Access Point
 Gateway
 Repeater
 Super WDS
 WISP
Channel Width
20MHz, 40MHz, 80MHz
Encryption Type
64-/128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK, 802.1X
Wireless Security
Enable/Disable SSID Broadcast
Wireless MAC address filtering
User Isolation
Max. SSIDs
8 ( 4 per radio )
Max. Wireless Clients
128 ( 64 per radio )
Max. WDS Peers
4
Wireless QoS
Supports Wi-Fi Multimedia (WMM)
Wireless Advanced
Auto channel selection
5-level transmit power control (100%, 75%, 50%, 25% and 12.5%)
Client limit control, coverage threshold
Distance control (Auto Ack Timeout)
Wi-Fi channel analysis chart
Status Monitoring
Device status, wireless client List
PLANET Smart Discovery
DHCP client table
System Log supports remote syslog server
VLAN
IEEE 802.1Q VLAN (VID: 3~4094)
SSID-to-VLAN mapping up to 4 SSIDs
Self-healing
Supports auto reboot settings per day/hour
Management
Supports PLANET Hardware AP Controller
Applicable
controllers
[1]
:WS-1232P/WS-2864PVR/NMS-500/NMS-1000V
Remote management through PLANET DDNS/ Easy DDNS
Configuration backup and restoration
Supports UPnP
Supports IGMP Proxy
Supports PPTP/L2TP/IPSec VPN pass-through
SNMP v1/v2c/v3 support, MIB I/II, Private MIB
Remarks
1. ^ the feature will be supported through firmware/system upgrade
