BOOKLET MAKER INSTALLATION
1.3 BOOKLET MAKER INSTALLATION
1.3.1 ACCESSORY CHECK
Check the quantity and condition of the accessories in the box against the following list:
Description Q’ty
A. Exit arm Catcher .................................................................. 1
B. CommunicationCabletoSR5030nisher ........................... 1
C. Docking assembly (incl. 4 M4 nuts and 4 washers) ............. 1
D. Shift tray plate ...................................................................... 1
E. Exit tray plate ....................................................................... 1
F. Powercords ......................................................................... 3
G. Terminator plug, will always be installed onto BK5030 ........ 1
H. Terminator plug TR5030 ....................................................... 1
I. Interlock Jumper TR5030 ..................................................... 1
J. Cable protector ..................................................................... 1
K. Cable holder ......................................................................... 2
L. Cable ties, 100 mm .............................................................. 3
[A] [D]
[C]
[B] [E]
[F] [H]
[G]
[I]
[J]
[K] [L]
