Trimmer
Installation
TRIMMER INSTALLATION
Install Belt stacker
1. Loosen screws [A] ( x 2) on the Trimmer.
NOTE: Unless the Book folder BF5030 will be installed. If so, the Belt stacker
will be installed on to the Book folder instead.
2. Install the Belt stacker on to the Trimmer.
3. Secure the Belt stacker with the screws [A] ( x 2).
Trimmer
[A]
