Plockmatic CF5030 - TROUBLESHOOTING; FAULT CODE DESCRIPTIONS

25 November 2011
Trouble-
shooting
CF-4-1
FAULT CODE DESCRIPTIONS
4. TROUBLESHOOTING
4.1 FAULT CODE DESCRIPTIONS
Fault Item Fault description Page
code No.
CF-001 CF-M15 Feed Motor Short Circuit .................................................................... CF-4-2
CF-002 CF-M15 Feed Motor Open Circuit .................................................................... CF-4-2
CF-003 CF-M15 Feed Motor Pulse Time Out Q28 ....................................................... CF-4-3
CF-004 CF-M16 Cover Drive Motor Short Circuit ........................................................ CF-4-5
CF-005 CF-M16 Cover Drive Motor Open Circuit ........................................................ CF-4-5
CF-006 CF-M16 Cover Drive Motor Pulse Time Out Q29 ............................................ CF-4-6
CF-007 CF-M17/18 Blower Motors Open Circuit .............................................................. CF-4-7
CF-008 CF-Q31 Empty Bin Sensor Faulty ................................................................... CF-4-8
CF-009 CF-Q30 DSD Sensor Faulty ............................................................................. CF-4-9
CF-010 CF-Q32 Paper Positioning Sensor Faulty .................................................... CF-4-10
CF-011 CF-Q33 Paper Bin Low Sensor Faulty ...........................................................CF-4-11
CF-012 CF-Q38 Paper Format Sensor Faulty ............................................................ CF-4-12
CF-201 CF-Q31 Empty Bin Sensor process .............................................................. CF-4-13
CF-202 CF-Q30 DSD Sensor Not activated in time ................................................... CF-4-13
CF-204 CF-Q32 Paper Positioning Sensor Not activated in time ............................ CF-4-14
CF-205 CF-Q32 Paper Position. Sensor Activated too long ................................... CF-4-14
CF-206 CF-Q30 DSD Sensor Double Feed ................................................................ CF-4-15
CF-207 CF-Q30 DSD Sensor Not activated when Paper Position Sensor
(Q32) is activated CF-4-15
CF-501 Paper Bin Low ................................................................................... CF-4-15
CF-502 Wrong Cover/Format ........................................................................ CF-4-16
CF-503 Empty Bin idle ................................................................................... CF-4-16
