Plockmatic CF5030 - DETAILED SECTION DESCRIPTIONS; ELECTRICAL COMPONENT LIST

25 November 2011
Detalied de-
scription
CF-6-1
ELECTRICAL COMPONENT LIST
6. DETAILED SECTION DESCRIPTIONS
6.1 ELECTRICAL COMPONENT LIST
Page Grid
code
CF-M15 Feed motor ............................................................................................. CF-6-2 .......... N5
CF-M16 Drive motor ............................................................................................ CF-6-2 ....O5/M5
CF-M17/
M18 Blower motors ....................................................................................... CF-6-3 .......... N5
CF-Q31 Empty bin sensor .................................................................................. CF-6-3 ..........Q6
CF-Q30 Paper path / DSD detection sensor (Phototransistor) ....................... CF-6-3 .......... P6
CF-Q30 Paper path / DSD detection sensor (LED) ........................................... CF-6-3 .......... P6
CF-Q32 Paper positioning sensor ..................................................................... CF-6-3 .......... S6
CF-Q33 Paper bin low sensor ............................................................................ CF-6-2 .......... S6
CF-Q38 Paper width sensor ............................................................................... CF-6-2 .......... R6
