Text on figures
(1) Pressure equalization
(2) Menu
• Section A shows information regarding the dryer operation (e.g. the Pressure in vessels A
and B, the Dryer Pressure Dewpoint, the Dryer Inlet temperature).
• Section B shows Status icons. Following icon types are shown in this field:
• Fixed icons
These icons are always shown in the main screen (e.g. Dryer stopped or running, Dryer
status).
• Optional icons
These icons are only shown if their corresponding function is activated (e.g. week timer,
automatic restart after voltage failure, etc.).
• Pop up icons
These icons pop up if an abnormal condition occurs (warnings, shutdowns, service,...).
To call up more information about the icons shown, select the icon using the scroll keys and
press the enter key.
• Section C is called the Status bar.
This bar shows the text that corresponds to the selected icon. When the menu button is
selected, this text shows the operational state of the dryer.
• Section D shows the Action buttons. These buttons are used:
• to call-up or program settings.
• to reset a service message.
• to have access to all data collected by the controller.
The function of the buttons depends on the displayed menu. The most common functions
are:
Designation Function
Menu To go to the menu
Modify To modify programmable settings
Reset To reset a timer or message
To activate an action button, highlight the button by using the Scroll keys and press the
Enter key.
To go back to the previous menu, press the Escape key.
Instruction book
30 2920 7111 23
