PH 230 PH 275 PH 350 PH 420 PH 550
Desiccant type Activated
alumina
Activated
alumina
Activated
alumina
Activated
alumina
Activated
alumina
Desiccant amount
per vessel
kg 9.9 12.4 14.8 12.4 14.8
Desiccant amount
per vessel
lb 21.8 27.3 32.6 27.3 32.6
Inlet filter 1 PF 6C HE PF 7C HE PF 8C HE PF 8C HE PF 9C HE
Outlet filter 1 PF 6S HE PF 7S HE PF 8S HE PF 8S HE PF 9S HE
Maximum air outlet
temperature
°C 60 60 60 60 60
Maximum air outlet
temperature
°F 140 140 140 140 140
Minimum volume
flow at inlet
l/s 27.5 32.5 41.25 48.75 65
Minimum volume
flow at inlet
cfm 58.3 68.9 87.45 103.35 137.8
Standard version, PDP -40 °C
PH 55 PH 75 PH 95 PH 120 PH 140 PH 190
Volume flow at
dryer inlet
l/s 25 35 45 55 65 90
Volume flow at
dryer inlet
cfm 53 74 95 116 138 191
Pressure drop at
maximum flow
bar 0.030 0.059 0.107 0.171 0.251 0.107
Pressure drop at
maximum flow
psi 0.44 0.86 1.55 2.48 3.64 1.55
Time to half a
cycle
s 87 87 87 87 87 87
Regeneration time s 65 65 65 65 65 65
Pressurization time s 20 20 20 20 20 20
Average
regeneration air
consumption
% 18.5 18.5 18.5 18.5 18.5 18.5
Desiccant type Activated
alumina
Activated
alumina
Activated
alumina
Activated
alumina
Activated
alumina
Activated
alumina
Desiccant amount
per vessel
kg 6.8 7.4 9.9 12.4 14.8 9.9
Desiccant amount
per vessel
lb 15.0 16.3 21.8 27.3 32.6 21.8
Inlet filter 1 PF 3C HE PF 4C HE PF5C HE PF 5C HE PF 6C HE PF 6C HE
Outlet filter 1 PF 3SHE PF 4S HE PF 5S HE PF 5S HE PF 6S HE PF 6S HE
Maximum air outlet
temperature
°C 60 60 60 60 60 60
