PH 55 PH 75 PH 95 PH 120 PH 140 PH 190
Maximum air outlet
temperature
°F 140 140 140 140 140 140
Minimum volume
flow at inlet
l/s 6.25 8.75 11.25 13.75 16.25 22.5
Minimum volume
flow at inlet
cfm 13.25 18.55 23.85 29.15 34.45 47.7
PH 230 PH 275 PH 350 PH 420 PH 550
Volume flow at
dryer inlet
l/s 110 130 165 195 260
Volume flow at
dryer inlet
cfm 233 275 350 413 551
Pressure drop at
maximum flow
bar 0.171 0.251 0.447 0.251 0.494
Pressure drop at
maximum flow
psi 2.48 3.64 6.48 3.64 7.16
Time to half a
cycle
s 87 87 87 87 87
Regeneration time s 65 65 65 65 65
Pressurization time s 20 20 20 20 20
Average
regeneration air
consumption
% 18.5 18.5 18.5 18.5 18.5
Desiccant type Activated
alumina
Activated
alumina
Activated
alumina
Activated
alumina
Activated
alumina
Desiccant amount
per vessel
kg 12.4 14.8 18.8 14.8 18.8
Desiccant amount
per vessel
lb 27.3 32.6 41.4 32.6 41.4
Inlet filter 1 PF 6C HE PF 7C HE PF 8C HE PF 8C HE PF 9C HE
Outlet filter 1 PF 6S HE PF 7S HE PF 8S HE PF 8S HE PF 9S HE
Maximum air outlet
temperature
°C 60 60 60 60 60
Maximum air outlet
temperature
°F 140 140 140 140 140
Minimum volume
flow at inlet
l/s 27.5 32.5 41.25 48.75 65
Minimum volume
flow at inlet
cfm 58.3 68.9 87.45 103.35 137.8
Instruction book
2920 7111 23 85
