1.14
9850045 R01 - 2020-2021 RANGER 1000 Service Manual
© Copyright Polaris Inc.
TRANSMISSION
PART DESCRIPTION
TORQUE SPECIFICATION
Bearing Cover Retaining
Fastener
9 ft-lbs (12 Nm)
Bell Crank Nut
14 ft-lbs (19 Nm)
Differential Cover Fastener
26 ft-lbs (35 Nm)
Fork Retainer Fastener
9 ft-lbs (12 Nm)
Park Plate Fastener
9 ft-lbs (12 Nm)
Rear Mount Bracket
Fastener
20 ft-lbs (27 Nm)
Rear Transmission Mount
Bracket Fastener
40 ft-lbs (54 Nm)
Rear Transmission Mount
Fastener
22 ft-lbs (30 Nm)
Ring Gear Fasteners 28 ft-lbs (38 Nm)
Sector Cover Fastener
10 ft-lbs (14 Nm)
Shift Cable Bracket
Fasteners
20 ft-lbs (27 Nm)
Shift Cable Fastening Nut 13 ft-lbs (18 Nm)
Shift Cable Locknut
13 ft-lbs (18 Nm)
Snorkel Locking Fastener 9 ft-lbs (12 Nm)
Solenoid
25 ft-lbs (34 Nm)
Speed Sensor 10 ft-lbs (14 Nm)
Transmission Case Fastener
20 ft-lbs (27 Nm)
Transmission Fill / Drain
Plug
12 ft-lbs (16 Nm)
Transmission to Engine
Mount
45 ft-lbs (61 Nm)
FINAL DRIVE
PART DESCRIPTION
TORQUE SPECIFICATION
Front Gearcase Cover Plate
Fastener
9 ft-lbs (12 Nm)
Front Gearcase Fill / Drain
Plug
10 ft-lbs (14 Nm)
Front Gearcase Mounting
Fastener
44 + 90° ft-lbs (60 + 90°
N·m)
Front Hub Castle Nut
80 ft-lbs (108 Nm)
Prop shaft Carrier Fastener 40 ft-lbs (54 Nm)
Rear Wheel Hub Castle Nut
180 ft-lbs (244 N·m)
Prop Shaft Fastener
22 ft-lbs (30 Nm)
GENERAL INFORMATION
