9850045 R01 - 2020-2021 RANGER 1000 Service Manual
© Copyright Polaris Inc.
1.15
STEERING / SUSPENSION
PART DESCRIPTION
TORQUE SPECIFICATION
Front Upper Ball Joint Pinch
Fastener
45 ft-lbs (61 Nm)
Front Lower Ball Joint Nut
42 ft-lbs (57 Nm)
Lower Steering Shaft Pinch
Fastener
25 ft-lbs (34 Nm)
Lower Steering Shaft to
Rack Pinch Fastener
48 ft-lbs (65 Nm)
Power Steering Mount
Fastener
30 ft-lbs (41 Nm)
Power Steering Unit Frame
Fastener
14 ft-lbs (19 Nm)
Rear A-Arm to Frame
Fastener
45 ft-lbs (61 Nm)
Rear Lower A-Arm to
Bearing Carrier Fastener
(M12)
30 ft-lbs (40 N·m) + 180°
Rear Upper A-Arm to
Bearing Carrier Fastener
(M10)
44 ft-lbs (60 N·m)
Shock Mounting Fastener
40 ft-lbs (54 Nm)
Stabilizer Bar Link Fastener
17 ft-lbs (23 Nm)
Stabilizer Bar Link Nut
40 ft-lbs (54 Nm)
Stabilizer Bar Mount
Fastener
31 ft-lbs (42 Nm)
Steering Adjustment Shock
Assembly Nut
7 ft-lbs (10 Nm)
Steering Rack Mounting
Nuts
40 ft-lbs (54 Nm)
Steering Wheel Nut 65 ft-lbs (88 Nm)
Steering Wheel Tilt
Assembly Nut
40 ft-lbs (54 Nm)
Tie Rod Jam Nut
13 ft-lbs (18 Nm)
Tie Rod Retaining Nut
Step 1: 30 ft-lbs (41 Nm)
Step 2: Tighten additional
90°
Upper Steering Shaft Pinch
Fastener
25 ft-lbs (34 Nm)
BRAKE SYSTEM
PART DESCRIPTION
TORQUE SPECIFICATION
Brake Line Banjo Bolt 15 ft-lbs (20 Nm)
Brake Switch
15 ft-lbs (20 Nm)
Caliper Bleed Screw 48 in-lbs (5.4 Nm)
Front Brake Disc Mounting
Fastener
18 ft-lbs (24 Nm)
Front Caliper Mounting
Fastener
28 ft-lbs (38 Nm)
Master Cylinder Banjo
Fastener
15 ft-lbs (20 Nm)
Master Cylinder Mounting
Fastener
20 ft-lbs (27 Nm)
Pedal Bracket Nuts
8 ft-lbs (11 Nm)
Rear Brake Disc Mounting
Fastener
28 ft-lbs (38 Nm)
Rear Caliper Mounting
Fastener
46 ft-lbs (62 Nm)
GENERAL INFORMATION
1
