10.Remove seat base fastener
y
to allow room for fuel
tank to slide out of the frame.
11. Rotate and slide the fuel tank and remove the tank
from vehicle.
INSTALLATION
1. Install the fuel tank in the vehicle.
2. Secure the seat base fastener
y
and torque to
specification.
TORQUE
Seat Base Fastener:
10 ft-lbs (14 Nm)
3. Connect the three plastic ties
t
to retain the main
wire harness to the fuel tank.
FUEL SYSTEM
