11.28
9850045 R01 - 2020-2021 RANGER 1000 Service Manual
© Copyright Polaris Inc.
7. Remove the center headliner from the vehicle.
NOTICE
If equipped, removing the dome light may ease removal
of the headliner. This can also prevent damage to the
headliner and dome light.
8. Remove the two T30 fasteners from the front
headliner.
9. Lower the front headliner.
INSTALLATION
1. Install the front headliner and tuck behind the ROPS
on both sides.
2. Loosely install the two T30 fasteners from the front
headliner.
3. Install the five push rivets to secure both headliners to
the windshield plate.
BODY / FRAME
