Administrator’s Guide for the VSX Series
11 - 4
Network
Video
Diagnostic Screen Description
Near End Loop Tests the system’s audio and video circuitry, camera
and monitor.
The monitor displays the video and plays the audio
that would be sent to the far site in a call.
This test is not available when you are in a call.
PING Tests whether the system can establish contact with a
far-site IP address that you specify.
If the test is successful, the VSX system displays a
message indicating that the IP address under test is
available.
Trace Route Tests the routing path between the local system and
the IP address entered.
If the test is successful, the VSX system lists the hops
between the system and the IP address you entered.
Diagnostic Screen Description
Video Diagnostics Tests the color settings of your monitor for optimum
picture quality.
If the color bars generated during the test are not
clear, or the colors do not look correct, the monitor
needs to be adjusted.
