Setting Up Your System Hardware
2 - 21
The following illustrations show microphone placement for different room
layouts.
Place microphones so that:
• The logo on each microphone points toward the monitor.
• The microphone closest to the monitor is parallel with, or in front of, the
person nearest the monitor.
After you power on the system, you will need to configure the system to send
stereo as described in Configuring StereoSurround Settings on page 4-21.
Square Table
Long Table
Wide Table
Round Table
One Microphone
Two Microphones
Three Microphones
