Polycom VSX 3000

Networks
2 - 23
5. Select and configure these settings:
6. Select and select a channel to activate or deactivate it. Active
channels are represented by a green icon, and inactive channels are
represented by a gray icon.
Configuring the Serial V.35/RS-449/RS-530 Network Interface
To configure the V.35/RS-449/RS-530 network interface settings:
1. Go to System > Admin Settings > Network > V.35/RS-449/RS-530.
2. Configure these settings:
Setting Description
PRI Line Type Displays read-only information about the system
and its configuration.
Number of Active Channels
D Channel Location
Network Mode
Clock Source
Terminal Endpoint ID
TEI
Line Termination
PRI E1 only
Make sure that channels are activated and deactivated only by a knowledgeable
network professional so that the system operates properly and can dial at the
desired rates.
Setting Description
Enable
V.35/RS-449/RS-530
Allows the system to connect to a terminal adapter using
a V.35, RS-449, or RS-530 connection.
V.35 Ports Used Specifies whether one or two lines are connected.
RS-366 Dialing Allows users to dial calls from this system.
Clear this setting if this is a dedicated connection or if
another device is used for dialing calls.
Area Code
Port 1
Port 2
Specifies the area code and number(s) that other sites
dial to reach this system.
If this is a dedicated connection, leave these fields blank.
