Statistics and Diagnostics
11 - 7
To view and download the CDR via the system’s web interface:
1. On a PC, open a web browser.
2. In the browser address line, enter the system’s IP address, for example,
http://10.11.12.13
, to go to the system’s web interface.
3. Enter
admin
as the user name, and the remote access password, if a
password has been established.
4. Click Utilities > Call Detail Report to view the details of the file.
5. Click Save and then specify a location on your computer to save the file.
Information in the CDR
The following table describes the data fields in the CDR.
As an added security feature, downloading the CDR file with the format
xxx.xxx.xxx.xxx/localcdr.csv requires a username and password in VSX system
software version 8.5.2 and later.
Data Description
Row ID Each call is logged on the first available row. A call is a
connection to a single site, so there may be more than one
call in a conference.
Start Date The call start date, in the format dd-mm-yyyy.
Start Time The call start time, in the 24-hour format hh:mm:ss.
End Date The call end date.
End Time The call end time.
Call Duration The length of the call.
Account Number If Require Account Number to Dial is enabled on the
system, the value entered by the user is displayed in this
field.
Remote System
Name
The far site’s system name.
Call Field Number 1 The number dialed from the first call field, not necessarily
the transport address.
For incoming calls — The caller ID information from the first
number received from a far site.
Call Field Number 2
(If applicable for
call)
For outgoing calls — The number dialed from the second
call field, not necessarily the transport address.
For incoming calls — The caller ID information from the
second number received from a far site.
