Networks
2 - 5
To configure the system to use a gatekeeper:
1. Go to System > Admin Settings > Network > IP > H.323 Settings.
2. Select and configure these settings on the Gatekeeper screen:
Setting Description
Use Gatekeeper Specifies whether to use a gatekeeper. Gateways and
gatekeepers are required for calls between IP and ISDN.
• Off — Calls do not use a gatekeeper.
•Auto — System automatically attempts to find an
available gatekeeper.
• Specify — Calls use the specified gatekeeper. Enter the
gatekeeper’s IP address or name (for example,
gatekeeper.companyname.usa.com, or 10.11.12.13).
• Specify with PIN — Calls use the specified E.164
address and require an Authentication PIN. This setting
is available only when the Avaya® option key is installed.
H.323 Name Specifies the name that gatekeepers use to identify this
system. You can make point-to-point calls using H.323
names if both systems are registered to a gatekeeper.
The H.323 Name is the same as the System Name, unless
you change it. Your organization’s dial plan may define the
names you can use.
H.323 Extension
(E.164)
Lets users place point-to-point calls using the extension if
both systems are registered with a gatekeeper, and specifies
the extension that gatekeepers and gateways use to identify
this system.
The default H.323 Extension is based on the system serial
number, but it can be changed. Your organization’s dial plan
may define the extensions you can use.
Primary
Gatekeeper IP
Address
If you chose to use an automatically selected gatekeeper,
this area displays the gatekeeper that was discovered in the
network.
If you chose to specify a gatekeeper, enter the IP address of
the primary gatekeeper.
Authentication
PIN
Specifies the password PIN to use for authentication with the
Avaya COMMUNICATIONS MANAGER®. This setting is
available when Use Gatekeeper is set to Specify with PIN.
