Closed chamber welding heads with impulse generator
Weld head
type
Minimum
diameter
(mm)
Maximum
diameter
(mm)
Reference
number
(R30)
Number of
impulses per
revolution
Factor C
(VP=C*VL/D)
H 500A 3.17 12.7 B007 366 12
HD 500 P 3.17 12.7 B007 366 12
HD 750 P 4.75 19.05 B009 369 16
HD 1500 P 6 38.1 B015 364 26
K 375 a 1.6 9.5 B009 341 15
K 375 n 1.6 9.5 A016 367 28
K 875 a 3.17 22.2 B010 355 17
K 875 n 3.17 22.2 A018 367 32
K 1500 6.35 38.1 B025 362 44
K 2000 12.7 50.8 B025 356 43
K 2500 12.7 63.5 B028 360 49
K 3000 25.4 76.2 B031 363 54
K 4000 38.1 101.6 B038 359 66
K 6000-T 50.8 152.4 A110 362 190
K 7000 76.2 177.8 A200 360 347
MW40 6 40 D023 C 360 40
MW65 10 65 D034 C 365 60
MW115 10 115 D073 C 358 126
MW170 10 170 C103 C 359 178
MW1250 6 33.4 C017 369 30
MW2500 9.5 63.5 C047 358 81
MW4500 25 114.3 A119 359 206
UHP 250 1.6 6.35 D006 384 11
UHP 500 3.0 12.7 D009 360 16
UHP 1500 6.0 38.1 D023 360 40
* a : previous
n : new
