Tachometer controlled closed chamber welding heads
Weld head
type
Minimum
diameter
(mm)
Maximum
diameter
(mm)
Reference
number
(R30)
Number of
impulses per
revolution
Factor C
(VP=C*VL/D)
K 375 1/16 3/8 G018 367 32
K 875 1/8 7/8 G018 367 32
K 875 (option) 1/8 7/8 G009 367 16
K 1500 1/4 1/12 G018 367 32
K 2000 1/2 2 F037 357 64
K 2500 1/2 2 1/2 F037 357 64
K 300 1 3 F037 357 64
K 4000 1 1/2 4 F037 357 64
K 6000 2 6 G183 361 318
K 7000 3 7 G183 361 318
H 500 1/8 1/2 G018 367 32
H 750 1/8 1/4 G018 367 32
H 1500 3/16 1 1/2 G018 367 32
MW 1250 1/8 1 5/16 G018 367 32
MW 2500 1/2 2 1/2 F037 357 64
MW 4500 2 4 1/2 F073 362 127
UHP 250 A 1/16 1/4 G006 367 11
UHP 500 A 1/8 1/2 G009 367 16
UHP 1500 A 1/2 1 1/2 G018 367 32
