3-10
3 First Steps
Data acquisition
board
The connections of the ADQ7DC data acquisition board are shown in the
following figure.
Figure 3.7: View of the data acquisition board
1SYNC
signal connection (SMA jack)
2TRIG
signal connection (SMA jack)
3GPIO
signal connection (44-pin High density Sub-D jack)
4B
signal input (SMA jack)
5X
signal input (SMA jack)
6A
signal input (SMA jack)
7CLK
signal connection (SMA jack)
&/.
75,*
6<1&
$
;
%
*3,2
67$7
5'<
86(5
3:5
