Series - Installation, Operation and Maintenance
DOC# SVW06-STARTUP-20170630
NOTE: Failure to add the correct amount and type of refrigerant and oil will void the warranty.
If equipped with remote or integrated water-cooled condenser for air cooling, verify water flow is present. On a
chilled water condenser, verify that the bypass valve over the water-regulating valve is OPEN.
___ 1.
Open the ball valves to the A/C condenser (not present on RoofComPak integrated ACC).
___ 2. To place the controller into Demand Control AIR COOL Mode: Press the PRG (
) button. Press the
UP ARROW () to select “Main Menu – Service” and then press the ENTER (↵) button. “Password
Required” is displayed. Use the UP ARROW () to change the number to: 0005 and press the ENTER
(↵) button.
Press the UP ARROW () to select “Main Menu – Service – Manual Mode” and then press the
ENTER (↵) button. “Password Required” is displayed. Use DOWN ARROW () to change the number
to: 9995 and press the ENTER (↵) button. The display should show “Main Menu – Service – Manual
Mode – Demand Control”. Press the ENTER (↵) button.
Press the ENTER (↵) button to move the cursor next to “CMPR HEAT”. Press the UP ARROW () to
change it from YES to NO and press ENTER (↵).
Press the ENTER (↵) button to move the cursor next to “AIR COOLING”. Press the UP ARROW ()
to change it from NO to YES and press ENTER (↵).
___ 3. After 10 minutes, press the PRG (
) button. The screen will show “Main Menu – Status Screens”.
Press ENTER (↵) then press the DOWN ARROW () and record the following data:
SPACE TEMP: °F OUTSIDE TEMP (Economizer units only): °F
SPACE RH: %
SPACE DEWPOINT: °F POOL TEMP (AW models only) °F
___ 4. Press the PRG (
) button. The screen will show “Main Menu – Status Screens”. Press the DOWN
ARROW () until “Main Menu – Detailed Status” is displayed and then press ENTER (↵). Press the
DOWN ARROW () and record the following data:
SURFACE TEMP: °F DISCH PRESS: PSIG
DEWPOINT: °F SUCT PRESS: °F
DEWPOINT SETPOINT: °F SUCT TEMP: °F
SUCT SH: °F
Amount of refrigerant added: Lbs. Compressor oil: Type: Amount: Oz.
Lineset info: Total length: Ft. Pipe Size: ” Vapor ” Liquid
Condenser Elevation: Ft. Circle one: Above or Below ComPak unit.
NOTE: Failure to add the correct amount and type of refrigerant and oil will void the warranty.
To Next Page
