UNIT RESET
___ 1. Once testing is complete, place the Control Power Breaker (CPBR) in the OFF position.
___ 2. Wait 15 seconds and then place the Control Power Breaker (CPBR) in the ON position. This will allow
the unit to start in automatic mode. It is essential to cycle power after performing manual testing.
PARALLEL CONTROL (Only applies when multiple ComPak units are controlling the same space)
___ 1. For multiple CPCS-PCP to control in parallel, there must be field-installed Category 5 cable run
between the ComPak control panel terminal strip T2, 22-24. Are the units interlocked? YES or NO
___ 2. Press the PRG (
) button. Press the UP ARROW () to select “Main Menu – Service” and then
press the ENTER (↵) button. “Password Required” is displayed. Use the UP ARROW () to change
the number to: 0005 and press the ENTER (↵) button.
Press the UP ARROW () to select “Main Menu – Service – Network Config” and then press the
ENTER (↵) button. “Password Required” is displayed. Use DOWN ARROW () to change the number
to: 9995 and press the ENTER (↵) button.
___ 3. Go through the options to set them per the job:
Enable Network Ctl: YES or NO Pool Temp Ctl: YES or NO Staged Dehum Ctl: YES or NO
REMOTE COMMUNICATIONS WIRING & SETUP
___ 1. Verify that the remote communications parameters in the CPCS-PCP are set properly from the factory
as required for LonWorks, Modbus, Bacnet IP or Bacnet MS/TP. See IOM for details.
___ 2. For LonWorks, Modbus and BACnet MS/TP, verify that the field wiring is connected to the terminals of
the serial card jack (BMS Card) on the bottom of CM1.
___ 3. If equipped with an Virtual-Tech RAP or BACnet IP, verify that the field provided Ethernet cable is
connected to the RJ-45 jack in the serial card slot of the CM1. Refer the customer’s IT staff to
complete the “CPCS-PCP RAP Network Configuration” form from www.poolpak.com. If this form is
complete, please use the CPCS-PCP to configure the addressing.
___ 4. Is the RAP or Building Automation System communicating? (If applicable) YES NO
SETPOINTS
___ 1. Enter the setpoints based on the build sheet in the control panel. Record the setpoints below:
Space temperature ____°F Space relative humidity ____%
Pool water temperature #1 ____°F Pool water temperature #2 ____°F
